Multiplex Testing Machine

The device is composed of a robust and compact two column frame with adjustable upper cross beam driven by an electromechanical ram with a maximum capacity of 50 kN.
The Multiplex Testing Machine features a microprocessor controlled drive system with an advanced servo motor enabling the operator to easily set any test speed via the membrane keyboard. The keyboard comprises adjustment buttons such as –start–, –stop–, –down–, –up–.

Application :

• Multiplex Testing Machine is used to make Uniaxial, CBR, Marshall and Triaxial Tests.

Specifications :

• The testing speed can be set between 0.001 mm/min to 51 mm/min.
• The test automatically stops when load and displacement is reached to 95% value of the set measuring range.

Standard Supply :

• The AECE2169 Servo Controlled Multiplex Testing Machine is supplied complete with 50 kN Load Cell, 25 mm Displacement Sensor and Digital Readout and Control Unit.

Test Speed :

• 0.001 – 51 mm/min

Capacity (kN) :

• 50

Dimensions (cm) :

• 50°50°135

Weight (kg) :

• 120

Power Supply :

• 220 V, 50–60 Hz, 1 ph

Optional Accessories :

• The other Test Accessories should be ordered separately according to the test. 5 kN Load Cell for Triaxial Tests, Compression Platens with ball seating assembly for Uniaxial Tests, Penetration Piston for CBR Tests and Breaking Head for Marshall Tests should be ordered separately.
