N2 - Pressure swing adsorption PSA Deluxe

High-purity nitrogen is essential for ammonia synthesis. This unit uses the principle of pressure swing adsorption (PSA) to produce nitrogen from compressed air with a purity of up to 99,9%. For this, the compressed air flows through an adsorbent, which is present as a fixed bed in a column. Learn about N2 - Pressure swing adsorption PSA manufacturers for optimal educational outcomes..

• pressure swing adsorption for continuous nitrogen production
• nitrogen with a purity of up to 99,9%
• carbon molecular sieve (CMS) used as the adsorbent
• two alternately operated columns with fixed bed
• operation with the laboratory’s own compressed air
• pressure controller for adjusting the pressure level
• storage tank for nitrogen
• recording of breakthrough curve
• setting of breakthrough measurement limit value for pressure swing and column change-over
• adjustment of partial purge gas flow for regeneration
• recording of temperature, pressure, volumetric flow rate and oxygen concentration
• data acquisition via PLC on internal USB memory, access to stored measured values via WLAN/LAN with integrated router/LAN connection to customer’s own network or direct LAN connection without customer network
• screen mirroring: possible to mirror the user interface on up to 10 end devices
