Newton's Ring Experiment Apparatus Enhanced Model Optics Educational Kits

The Newton's Ring Experiment Apparatus Enhanced Model Optics Educational Kits is an advanced optical system designed for accurate observation and measurement of Newton's Ring interference patterns. By integrating a high-resolution CMOS color camera and display system, the apparatus provides a modern and efficient alternative to conventional microscope-based measurements. The system captures interference fringes through a microscopic imaging setup and displays them directly on a color monitor for real-time observation. Built-in measurement functions with keypad-controlled cursors allow users to determine fringe separations accurately, simplifying calculations and improving experimental precision. The apparatus is ideal for studying optical interference, thin film phenomena, and the determination of lens curvature. Its digital imaging and measurement capabilities make it highly suitable for physics laboratories, optics education, and research applications. Physics Lab Experiments from Atico Exports.

• Observation of Newton's Ring Interference Patterns
• Measurement of Fringe Diameters and Separation
• Determination of Radius of Curvature
• Thin Film Interference Studies
• Wave Optics Experiments
• Physics and Optics Laboratory Training

Light Source :

• Low-Pressure Sodium Lamp, 20 W

Newton's Ring Device :

• Radius of Curvature: Approx. 868.5 mm
• Diameter: 32 mm
• Transmissive Type

Electronic Scale Resolution :

• 0.01 mm

Viewing Field :

• Approx. 10 mm

CMOS Color Camera Sensor Size :

• 1/4"

Camera Resolution :

• 1280 × 1024 Pixels

Pixel Size :

• 2.8 μm × 2.8 μm

Bit Depth :

• 8 Bit

Output Format :

• VGA

Frame Rate :

• 15 Hz

Optical Mount :

• C/CS Mount

Camera Controls :

• Keypad and Menu Controlled

Menu Functions :

• Brightness
• Contrast
• Saturation
• Sharpness
• Tone
• Cursor
• Length

Camera Lens Focal Length :

• 25 mm

Sodium Lamp with Housing and Power Supply :

• Quantity: 1 Set

CMOS Color Camera with AC Adapter :

• Quantity: 1 Set

Camera Lens with Extension Ring :

• Quantity: 1

Newton's Ring Assembly :

• Quantity: 1

Beam Splitter with Mount and Post :

• Quantity: 1 Set

Camera Stand with Focusing Knob :

• Quantity: 1 Set

Keypad Controller :

• Quantity: 1

VGA Flat Panel Monitor (Optional) :

• Quantity: 1

• Microscopic CMOS Color Camera with Measurement Cursor
• Newton's Ring Pattern Display on VGA Color Monitor
• Direct Measurement Using Keypad-Controlled Cursor
• Real-Time Observation and Analysis
• Camera and Sodium Lamp Suitable for Multiple Laboratory Applications
• Detailed Instruction Manual
