Non-Nuclear Asphalt Density Gauge, Touch Screen, New Model

Operational Features

Status Bar :

• Displays GPS status, Data Save status, battery voltage, low battery and date and time.
  Storage :
• Built-in 512M memory, stores up to 40000 project measurement points with details, and up to 200 models.
  Data Logging :
• When enabled, stores all measurements taken in single or average modes (Status Bar Icon)
  Reports :
• Easily download data to be imported into Excel.
  GPS Control :
• • When activated will display latitude and longitude positions, number of satellites the gauge is connected to as well as the UTC date and time, also available in UTM format. GPS information will store with each measurement when Data Save and GPS feature is enabled (Status Bar Icon)
    Update Software :
• One touch upload of new software using a USB memory stick.
  Data Management :
• Quickly Access, download or delete your project data.
  Set Time & Date :
• Quick time and date setup, MM/DD/YY and DD/MM/YY formats.
  Units :
• Interchangeable settings for Density (kg/m3, lb/ft3), Temp , Depth (in, mm) and Stone Size (in, mm).
• Enhanced Customer Support
• Diagnostic screen to aid in factory Support.
• User Programmable Target Density
• Used for calculating % compaction.

STANDARDS COMPLIANCE :

• COMPLIED AS PER ASTM D 7113-05, AASHTO T 343-12

Dimensions (mm) :

• 260-260-237

Weight (kg) :

• 3.25

Technical Specifications

Modes

• Single: Reading time less than five (5) seconds. Stores Data.
• Average: Averages five (5) readings and stores data including date and time.
• Continuous: Instantaneous density readings.

Functions

• Density: % Compaction, % Porosity.
• Integrated Temperature Sensing: Real time temperature display 0 C to 350 C.

Calibration Modes

• Normal: Correlation offset to cores.

Measurement Specifications

• Sensing Area: 260mm diameter base allows optimum measurement on fine and coarse material types.
• Measurement Depth: 300 mm.
• Measurement Display: Density, % Compaction, Surface Temperature, Mix Name & Project Name.

Electrical Specifications

• Microprocessor Controlled.
• Battery: 1300mAh ternary lithium battery.
• Recharge Life: >15h.
• Battery charger: DC5V 2A.
• Computer Ports: 1 USB Port.

• 7.0 in full color graphics driven user interface, touch screen operation, easy to use.
• New status bar feature, displays GPS status, data save status, available battery voltage, low battery status and date and time.
• New data management feature, quickly access, download or delete your project data.
• Ability to download files from the device via USB drive.
• Fast, reliable, accurate material density and compaction test, and repeatable readings in real time, user friendly, cost effective.
• Non-Nuclear means no badges, licenses or storage and transport concerns.
