Nonlinear Circuit Chaotic Experimental Apparatus

Experiments :

• Measurement of the inductance of a ferrite-core inductor at different current levels using an RLC series resonance circuit.

Experiments :

• Observation of waveforms generated by an LC oscillator before and after RC phase shifting using an oscilloscope.

Experiments :

• Observation and analysis of phase diagrams (Lissajous figures) corresponding to the oscillator waveforms.

Experiments :

• Investigation of periodic changes in phase figures by varying the resistance of the RC phase-shifting network.

Experiments :

• Recording and study of bifurcation, intermittency chaos, period-tripling, attractors, and double-attractor phenomena.

Experiments :

• Measurement of voltage-current characteristics of a nonlinear negative-resistance circuit.

Experiments :

• Analysis of chaos generation through the dynamic equations of nonlinear electronic circuits.

Digital Voltmeter :

• 4½-digit display.
• Measuring Range: 0–20 V.
• Resolution: 1 mV.

Nonlinear Circuit Element :

• Dual operational amplifier-based nonlinear module with associated resistor network.

Power Supply :

• Dual DC output: ±15 V.

Standard Accessories :

• Main Experimental Unit – 1 No.
• Inductor – 1 No.
• Magnet – 1 No.
• Dual Operational Amplifier Modules – 2 Nos.
• Jumper Wires – 11 Nos.
• BNC Cables – 2 Nos.
• Instruction Manual – 1 No.

Designed For :

• Physics Lab Experiments from Atico Exports.
