Oil Separation Apparatus for Oil Fuel and Petroleum Testing Instruments

The Lubricating Grease Pressure Bleeding Tester determines the tendency of lubricating grease to separate oil during storage in a 35 lb pail. The sample is placed on a sieve inside a special test cell and subjected to an air pressure of 0.25 psi (1.72 kPa) at a constant temperature. Any oil that separates from the grease during a 24-hour test period is collected in the cell and weighed. The system consists of pressure bleeding test cells, an air pressure regulation system, and a constant-temperature air cabinet capable of testing four samples simultaneously. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for lubricating grease testing applications.

Testing Capacity:

• Four samples simultaneously

Test Conditions:

• Air pressure: 0.25 psi (1.72 kPa)
• Test duration: 24 hours
• Temperature: 77°F (25°C)
• Controller sensitivity: ±1°F (±0.5°C)

Pressure Bleeding Test Cell:

• Type A test cell
• Cup assembly with funnel and positioning seat for beaker
• Cover with air inlet fitting
• 200-mesh stainless steel sieve strainer with brass support ring
• Bayonet-type connection and O-ring seal for tight closure between cover and base
• Cup, funnel, and base constructed of chrome-plated spun copper
• Test beaker ordered separately

Constant-Temperature Air Cabinet:

• Insulated, airtight cabinet accommodating four pressure bleeding test cells
• Electric heater, solid-state controller, cooling coil, and circulating fan
• Double-wall stainless steel construction with full insulation
• Temperature and air pressure control according to ASTM specifications

Air Pressure Regulation System:

• Air inlet pressure regulator with gauge
• Cartesian manostat
• Manifold with control valves for four test cells
• Output gauge
• Manostat
• Gas washing bottle
• Built-in pressure relief valve for protection against pressure surges

Power Supply:

• 115 V, 60 Hz, single phase, 3 A
• 220–240 V, 50/60 Hz, single phase, 1.5 A

Net Weight:

• 150 lbs (68.0 kg)

Optional Accessories:

• Thermometer
• Pressure bleeding test cell
• Test beaker
