EXPERIMENT: STUDY OF OP-AMP APPLICATIONS
EXPERIMENT SETUP CONSISTS OF:
- Complete Op-Amp Application Kit – Built-in power supply ±12 V (fixed and variable), set of known-value resistors (19 values), set of capacitors (10 values), set of Zener diodes, potentiometers 10 kΩ and 100 kΩ, R-2R network, op-amp IC connected in circuit, digital DC voltmeter 0–20 V, 0.01 V resolution, suitable for more than 20 different op-amp based experiments, set of patch cords
- Individual Experiment Circuits Using Op-Amp:
- Low-Pass Filter, High-Pass Filter & Band-Pass Filter
- Inverting & Non-Inverting Amplifier
- Integrator & Differentiator
- Phase Shift Oscillator
- Wien-Bridge Oscillator
- Adder & Subtractor
OPTIONAL:
- Signal Generator – Microcontroller-based digital signal generator producing frequency up to 1 MHz, 20 V p-p output in sine, square, triangular and pulse waveforms, digital display for frequency and waveform display
- Digital Storage Oscilloscope – 100 MHz dual channel, XY mode, 7 inch LCD display, 1 Gs/sec, supplied with 2 probes, automatic measurement of amplitude, frequency, rise time, etc.
Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.
