Optical Fiber Information and Optical Fiber Communication Physics Lab Experiment Setup

This experiment system is specially designed for laboratory courses in information optics and optical fiber communication. It provides a comprehensive platform for studying fiber optics, optical communication, optical fiber sensing, and signal processing technologies. With its compact structure, versatile functionality, and practical experimental content, the system serves as an effective educational and research tool for understanding the principles and applications of optical fiber technology.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Wavelength Division Multiplexing (WDM) Principle Experiment
• Optical Fiber and Light Source Coupling Experiment
• Mach-Zehnder Optical Fiber Interference Experiment
• Multimode Fiber Numerical Aperture Measurement Experiment
• Optical Fiber Temperature Sensing Principle Experiment
• Optical Fiber Transmission Loss Measurement Experiment
• Optical Fiber Pressure Sensing Principle Experiment
• Fiber Splitter Parameter Measurement Experiment
• Optical Transmitter Extinction Ratio Measurement Experiment
• Variable Optical Attenuator and Parameter Measurement Experiment
• Erbium-Doped Fiber Amplifier Principle Experiment
• Optical Fiber Isolator and Parameter Measurement Experiment
• Basic Fiber Optics Demonstration Experiment
• Optical Fiber Switch Experiment

Host :

• Temperature Control System
• Pressure Control System
• Fiber Coupling Frame, etc.

Portable Light Source :

• Wavelengths: 1310 nm / 1550 nm

Optical Power Meter :

• Wavelength Range: 800–1700 nm (850, 980, 1310, 1480, 1550 nm)

Laser :

• He-Ne Laser or Semiconductor Laser

High-Stability Light Source :

• Wavelength: 1310 nm
• Output Power ≤ 1 dBm

Error Code Instrument :

• External Clock Frequency: 2.4 Kbps–20 Mbps
• HDB3 Codec with 2048 Kbps Rate

Optical Power Meter Ranges :

• 2 μW
• 20 μW
• 200 μW
• 2 mW
• 20 mW
• 200 mW

Optical Fiber Components :

• 633 nm Single-Mode Fiber
• 633 nm Multimode Fiber
• 1 km Communication Fiber
• 980 nm Pump Laser
• Erbium-Doped Fiber
