Optical Image Addition Subtraction Experiments

This experiment kit is designed to study the principles of Fourier optics and optical image processing. It enables students to investigate Fourier optical filtering, understand the role of optical gratings in image addition and subtraction, and explore the structure and operation of a 4f optical system.

Output Power :

• 5.0 mW

Wavelength :

• 650 nm

Grating Density :

• 100 lines/mm

Length :

• 1 m

Beam Expander :

• f = 4.5 mm

Imaging Lens :

• f = 150 mm

Parts Included :

• Semiconductor Laser – 1
• Beam Expander (f = 4.5 mm) – 1
• Optical Rail – 1
• Carriers – 7
• One-Dimensional Grating – 1
• Plate Holder – 1
• Lens (f = 150 mm) – 3
• Lens Holders – 4
• White Screen – 1
• Laser Holder – 1
• Two-Axis Adjustable Holder – 1
• Small Aperture Screen – 1
