Optics 1 Geometrical Optics Physics Science Kits for Lab Use in Schools & Colleges ATICO Export

All experiments can be done in daylight:

• This experiment set enables all basic student experiments in geometric optics
• Experiments are quicker to perform than teacher demonstrations without losing precision
• A very bright halogen bulb allows experiments to be conducted even in daylight

Precisely parallel light beams without any calibration:

• The experiment lamp produces a precisely parallel beam of light immediately when switched on

• No calibration or adjustment is required

• Simply place the lamp on a table and connect it to a 12 V power supply

• The double U-shaped aluminium profile allows insertion of slides with 1, 2, 3 or 5 slits

• This enables generation of multiple parallel light rays

• A three-colour filter produces parallel beams in red, green and blue

No additional equipment required:

• No optical bench or platform is needed
• A frosted acrylic disc with angle graduations allows quick and precise readings
• Scratch-proof screen printing ensures durability
• The halogen bulb has a long lifespan and can be easily replaced

Included items:

• 1 × Storage case
• 1 × Inlay with cut-outs for apparatus, O1
• 1 × Experiment lamp
• 1 × Opaque aperture, O1
• 1 × Aperture with single slit and double slit
• 1 × Aperture with 3 and 5 slits
• 1 × Plane mirror
• 1 × Semi-cylindrical body
• 1 × Trapezoidal body
• 1 × 90° prism
• 1 × Coated plastic trough
• 2 × Plano-convex lenses
• 1 × Plano-concave lens
• 2 × Experiment leads, 75 cm
• 1 × Plane-/Concave mirror
• 1 × Disc with angle graduations, O1
• 1 × Three-colour filter
• 1 × Subtractive filter, yellow
• 1 × Subtractive filter, magenta
• 1 × Subtractive filter, cyan
• 1 × Crossing module

Additionally required:

• Low voltage power supply MKS 2.4
• Low voltage power supply MKS 3.1

Experiments:

• Light beams and rays
• Reflection from a plane mirror
• Apparent location of a mirror image
• Angled mirrors
• Focal point of a concave mirror
• Important rays for concave mirrors
• Refraction of light
• Parallel-sided blocks
• Refractive index between air and water
• Critical angle for total internal reflection
• Total internal reflection in prisms
• Fibre optics
• Focal points of a convex lens
• Important rays for convex lenses
• Apparent focal points for a concave lens
• Combinations of lenses
• Dispersion of white light
• Additive mixing of colours
• Subtractive mixing of colours
• Crossing light beams
