Hollow prism and raindrop model:

• The OPTICS 3 experiment set extends image and shadow experiments with additional studies on prism spectra and rainbows

• Lens and mirror frames are marked with principal planes for precise measurements

• Distances can be measured with an accuracy of up to 0.5 mm

• A hollow prism filled with water produces a clear spectrum

• Blocking the red light and adding sugar allows investigation of refractive index vs concentration

• A raindrop model filled with water enables creation of a realistic rainbow experiment

The universal track is also used as an optical bench:

• The same profiled rail from MECHANICS sets is used as an optical bench
• The scale begins about 15 cm from the end of the rail
• Objects (slides) can be placed directly at the zero mark
• Enables easy and precise measurement of object and image distances
• The universal track is not included in the set

Enhancement with wave optics:

• The OPTICS 3 set can be upgraded with the OPTICS 3 plus set
• Removing the cover reveals storage slots for diffraction and polarisation components

Included items:

• 1 × Storage case
• 1 × Inlay with cut-outs for apparatus, O+
• 1 × Cover element
• 1 × Stand rod, 10 cm
• 1 × White screen with scale
• 1 × Transparent screen
• 1 × Lens, +50, in holder
• 1 × Lens, +100, in holder
• 1 × Spatula
• 1 × Lens, +300, in holder
• 1 × Lens, –100, in lens holder
• 1 × Concave mirror in holder
• 1 × Simple lens holder
• 1 × Lens holder with slide holder
• 1 × Threaded rod
• 1 × F-shaped aperture
• 1 × Aperture with 4-mm hole
• 1 × Aperture with 2-mm hole
• 1 × Aperture with 1-mm hole
• 1 × Aperture with square hole
• 2 × Simple riders
• 1 × Rider with slot
• 1 × Lamp block
• 1 × Red filter in holder
• 1 × Slit aperture
• 1 × Rider with screw
• 1 × Raindrop model
• 1 × Hollow prism
• 1 × Platform

Additionally required:

• Experiment set OPTICS 1
• Universal track
• Low voltage power supply MKS 2.4
• Low voltage power supply MKS 3.1

Experiments:

• Formation of shadows
• Pinhole cameras
• Virtual and real images from a concave mirror
• Real images from a converging lens
• Magnifying glasses
• Microscopes
• Astronomical telescopes
• Galileo telescopes
• Reflecting telescopes
• Eye defects
• Stereoscopic vision
• Spectrum produced by a prism
• Concentration of a sugar solution
• Rainbows
