Optics Experiment Kit Basic Model

Experiments :

• Measurement of focal length using the autocollimation method.

Experiments :

• Measurement of focal length using Bessel’s method.

Experiments :

• Assembly and operation of a slide projector.

Experiments :

• Observation of Fresnel diffraction through a single slit.

Experiments :

• Observation of Fresnel diffraction through a circular aperture.

Experiments :

• Study of Young’s double-slit interference.

Experiments :

• Demonstration of Abbe’s imaging principle and optical spatial filtering.

Experiments :

• Experiments on pseudo-color encoding, theta modulation, and color composition.

Optical Carriers :

• General Carriers: 4 Nos.
• X-Translation Carriers: 2 Nos.
• X & Z Translation Carrier: 1 No.

Magnetic Base With Holder :

• 1 No.

Two-Axis Mirror Holders :

• 2 Nos.

Lens Holders :

• 2 Nos.

Plate Holder :

• 1 No.

White Screen :

• 1 No.

Object Screen :

• 1 No.

Iris Diaphragm :

• 1 No.

Adjustable Single-Slit Assembly :

• 1 No.

Laser Holder :

• 1 No.

Paper Clip Holder :

• 1 No.

Optical Rail :

• Length: 1 m.
• Material: Aluminum.

Beam Expander :

• Focal Length: 6.2 mm.

Mounted Lenses :

• Focal Lengths: 50 mm, 150 mm, and 190 mm.
• One each supplied.

Plane Mirror :

• Dimensions: Ø36 mm × 4 mm.

Transmission Grating :

• 20 lines/mm.

Two-Dimensional Orthogonal Grating :

• 20 lines/mm.

Circular Aperture :

• Diameter: 0.3 mm.

Transmission Character Plate With Grid :

• 1 No.

Zero-Order Filter :

• 1 No.

Theta Modulation Plate :

• 1 No.

Double-Slit Plate :

• 1 No.

Slide Projection Plate :

• 1 No.

Variable Intensity Tungsten Lamp :

• Rating: 12 V / 30 W.

He-Ne Laser :

• Output Power: Greater than 1.5 mW.
• Wavelength: 632.8 nm.

Designed For :

• Physics Lab Experiments from Atico Exports.
