Optics Experiment Kit Extended Model for Educational Physics Kits

The Optics Experiment Kit Extended Model for Educational Physics Kits is designed to provide comprehensive hands-on experience in geometrical optics, physical optics, optical polarization, and information optics. It offers a wide range of experiments that help students explore fundamental and advanced optical principles through practical laboratory work.
Students can assemble experimental setups using individual optical components, gaining valuable experience in optical system construction, alignment, and measurement techniques. The detailed instructional manual includes experimental principles, setup procedures, operating instructions, and component requirements for effective learning.
The kit supports experiments involving lens measurements, optical aberrations, interference, diffraction, polarization, optical activity, and image processing techniques, making it suitable for university and college-level physics education.

• Physics Lab Experiments from Atico Exports.

Geometrical Optics :

• Measurement of the focal length of a convex lens using Lens Imaging Equation
• Measurement of the focal length of a convex lens using Auto-Collimation Method
• Measurement of the focal length of a convex lens using Bessel Displacement Method
• Measurement of the focal length of a concave lens
• Study of spherical and chromatic aberrations of a convex lens
• Determination of nodal locations and focal length of a lens group
• Measurement of microscope magnification
• Measurement of telescope magnification

Interference :

• Young’s Double-Slit Interference
• Fresnel Biprism Interference
• Double Mirror Interference
• Lloyd’s Mirror Interference

Diffraction :

• Fraunhofer Diffraction of a Single Slit
• Fraunhofer Diffraction of a Circular Aperture

Polarization and Optical Activity :

• Polarization by Reflection and Brewster Angle
• Polarization by Dichroism
• Elliptical Polarization
• Circular Polarization
• Optical Activity (Polarization Rotation)

Information Optics :

• Abbe Imaging and Optical Spatial Filtering
• Pseudo-Color Encoding, Theta Modulation, and Color Composition

Optical Rail :

• Anodized Aluminum, Length 104 cm
• Quantity: 1

Adjustable Carrier :

• Two-Axis Translation
• Quantity: 2

Adjustable Carrier :

• One-Axis Translation
• Quantity: 1

Universal Carrier :

• Standard
• Quantity: 2–3

Kinematic Mirror Holder :

• Standard
• Quantity: 1

Lens Holder :

• Standard
• Quantity: 2–3

Adapter Piece :

• Extension to Both Ends
• Quantity: 1

Plate Holder :

• Standard
• Quantity: 1

White Screen :

• Standard
• Quantity: 1

Object Screen :

• Standard
• Quantity: 1

Single-Sided Adjustable Slit :

• Standard
• Quantity: 1

Lens Group Holder :

• Standard
• Quantity: 1

Spatial Filter Set :

• Low-Pass, High-Pass, Band-Pass, Directional, Zero-Order
• Quantity: 1

Optical Stop :

• Diameter 8 mm
• Quantity: 1

Fresnel Bi-Mirror :

• Standard
• Quantity: 1

Stand Ruler :

• Standard
• Quantity: 1

Microscope Holder :

• Standard
• Quantity: 1

Rotary Adjustable Slit :

• Standard
• Quantity: 1

Biprism Holder :

• Standard
• Quantity: 1

Laser Tube Holder :

• Standard
• Quantity: 1

45° Glass Holder :

• Standard
• Quantity: 1

Optical Goniometer :

• Standard
• Quantity: 1

Polarizer Holder :

• Standard
• Quantity: 3

Mounted Lenses :

• f = 45, 70, 105, 150, 190, 225, 300, -100 mm
• Quantity: 1 Each

Beam Expander :

• f = 4.5 mm
• Quantity: 1

Mounted Optical Filters :

• Red and Blue
• Quantity: 1 Each

Mounted Double Slit :

• d = 1.15 or 1.35 mm
• Quantity: 1

Mounted Biprism :

• Ø 36 mm
• Quantity: 1

Mounted Plane Mirror :

• Ø 36 mm
• Quantity: 1

Mounted Polarizers :

• Ø 20 mm
• Quantity: 2

Mounted Quarter-Wave Plate :

• λ = 632.8 nm, Quartz
• Quantity: 1

Mounted Reticle :

• 1/10 mm Film
• Quantity: 1

Mounted Millimeter Ruler :

• Length 30 mm Film
• Quantity: 1

Eyepiece :

• f = 32 mm, Doublet
• Quantity: 1

Black Glass Sheet :

• For Lloyd’s Mirror Experiment
• Quantity: 1

Measurement Microscope :

• Field Diameter 8 mm
• Quantity: 1

Liquid Cell with Support :

• Length 200 mm
• Quantity: 1

Low-Pressure Sodium Lamp :

• 20 W
• Quantity: 1

Bromine Tungsten Lamp :

• 12 V / 30 W, Variable
• Quantity: 1

He-Ne Laser :

• 1.5 mW @ 632.8 nm

• Quantity: 1

Ground Glass Screen :

• Standard
• Quantity: 1

Diffraction Pinhole :

• Ø 0.3 mm
• Quantity: 1

Grating :

• 20 Lines/mm
• Quantity: 1

Character with Grid :

• Standard
• Quantity: 1

Theta Modulation Plate :

• Standard
• Quantity: 1

2-D Cross Grating :

• Standard
• Quantity: 1

• 16 Fundamental Optics Experiments
• Cost-Effective Educational Solution
• Detailed Instructional Manual
• Easy Alignment and Setup
