Optimization of control loops

This experimental unit with the interaction between controller and controlled system, the objective being for the closed control loop, comprising the controller and the controlled system, to exhibit the desired optimum response. The setting of controller parameters – a key practical aspect – can be practised safely and intensively using simulation software. Concepts such as open and closed loop control, stability, step response, disturbance and control response are clearly demonstrated. Learn about Optimization of control loops Mechatronics Trainers9 India for optimal educational outcomes..

• experimental unit for controller tuning
• digital controller, configurable as a P, PI or PID controller with interface
• interface for PC
• simulation software for different controlled system types, such as first and second order lags, time-delayed systems etc.
• recording and evaluation of time response on PC
• configuration software for process controller
• software via USB under Windows 11
