OSBORNE REYNOLDS APPARATUS

Free-standing apparatus that gives a visual demonstration of laminar and turbulent flow.

Used for the illustration and investigation of Laminar and Turbulent flow, with the active flow visible thanks to a dye injection system and a glass bell mouth tube to allow easy viewing of the flow patterns. The flow rate of the water is controlled via a gate valve on the outlet which allows fine control. Varying the flow rate alters the flow from laminar to turbulent. Learn about OSBORNE REYNOLDS APPARATUS hydraulics-bench India for optimal educational outcomes.. The flow is created by a tank mounted around the bell mouth entry. The large capacity, even, water entry system in the base of the tank and the design of the bell mouth intake ensures laminar entry conditions into the tube. Learn about OSBORNE REYNOLDS APPARATUS specifications for optimal educational outcomes.. A thin tube extends into the inner tube and is connected to a header tank containing dye. When the dye is allowed to flow down this tube and is injected into the water stream it highlights the flow characteristics (aided by a UV tube mounted on the tube). Learn about OSBORNE REYNOLDS APPARATUS price for optimal educational outcomes.. It is then carried away by the flowing water, illustrating clearly the laminar or turbulent nature of the stream.
