Oxidation Stability Apparatus for Petroleum Testing Equipment

The Oxidation Stability Test Bath is designed to evaluate the oxidation stability of fuels and lubricants under controlled temperature and airflow conditions. Testing is generally performed at 95°C in the presence of oxygen or dry air. For inhibited mineral oils, the sample is reacted with oxygen in the presence of water and an iron-copper catalyst.

The apparatus consists of a constant-temperature liquid bath with solid-state temperature control, calibrated flowmeters, individual flow control valves, and a condenser water manifold. Each oxidation cell receives a controlled airflow of 3 L/h. The temperature controller provides rapid stabilization while minimizing overshoot. A redundant overtemperature protection circuit interrupts power if the bath exceeds the programmed temperature limit.

The bath features a double-wall insulated construction, copper immersion heaters, a circulation stirrer, and a stainless steel interior with a built-in support rack and overflow/drain arrangement.

Manufactured by Atico Export for dependable oxidation stability testing of fuels and lubricants in petroleum testing laboratories.

• Oxidation stability testing of fuels and lubricants
• Evaluation of inhibited mineral oils
• Assessment of resistance to oxidation under controlled conditions
• Quality control and research in petroleum laboratories

Capacity :

• 8 oxidation cells for the benchtop configuration
• 12 oxidation cells for the benchtop configuration
• 30 oxidation cells for the floor model configuration
• 60 oxidation cells for the floor model configuration

Temperature Range :

• 8-position bath: Ambient to 250°F (121°C)
• 12-position bath: Ambient to 212°F (100°C)

Temperature Control Stability :

• Exceeds applicable ASTM requirements

Airflow Rate :

• 3 L/h per oxidation cell

Bath Medium :

• 8-position bath: 9.9 US gallons (37.5 L) of white technical oil
• 12-position bath: 19.0 US gallons (71.9 L) of white technical oil

Heating System :

• Copper immersion heaters

Circulation System :

• 1/20 hp circulation stirrer

Bath Construction :

• Double-wall insulated design
• Stainless steel interior
• Built-in support rack with overflow and drain

Temperature Display :

• Actual and setpoint temperature in °C or °F

Power Supply :

• 115 V, 60 Hz, single phase, 19 A — 8-position configuration
• 220–240 V, 50/60 Hz, single phase, 10 A — 8-position configuration
• 115 V, 60 Hz, single phase, 32.6 A — 12-position configuration
• 220–240 V, 50/60 Hz, single phase, 17.0 A — 12-position configuration

• Available in 8-position and 12-position benchtop configurations
• Available in 30-position and 60-position floor models
• Solid-state temperature control
• Calibrated flowmeters with individual control valves for each oxidation cell
• Airflow delivery rate of 3 L/h per oxidation cell
• Condenser water manifold with individual control valves
• Rapid temperature stabilization with minimal overshoot
• Redundant overtemperature protection circuit
• Digital display of actual and setpoint temperatures in °C or °F
• Double-wall insulated bath construction
• Copper immersion heaters and circulation stirrer
• Stainless steel bath interior with built-in support rack
• Overflow and drain arrangement for maintaining the required immersion depth
• Oxidation cell glassware and accessories supplied separately
