Oxidation Stability Bath Mineral Insulating Oils for Petroleum Testing Equipment

The Oxidation Stability Test Bath is designed to determine the oxidation stability of mineral insulating and transformer oils by measuring the sludge and acid formed under prescribed accelerated aging conditions.

The apparatus features a constant-temperature oil bath that accommodates six oil receptacles at the required immersion depth. It maintains a test temperature of 110°C ± 0.5°C and supplies oxygen to each sample at a controlled flow rate of 1 L/h ± 0.1 L/h through six independent flowmeters mounted on a common manifold.

The insulated, double-wall stainless steel bath incorporates microprocessor-based temperature control, a digital setpoint and temperature display, and an automatic overtemperature cut-off circuit for safe and reliable operation.

Manufactured by Atico Export for dependable oxidation stability evaluation of mineral insulating oils in electrical and petroleum testing laboratories.

• Oxidation stability testing of mineral transformer oils
• Evaluation of mineral insulating oil degradation
• Measurement of sludge formation during oxidation
• Determination of acid formation under accelerated aging conditions
• Quality control and research in transformer oil testing laboratories

Sample Capacity :

• 6 samples

Temperature Range :

• Ambient to 230°F (110°C)

Test Temperature :

• 110°C ± 0.5°C

Temperature Control Stability :

• Exceeds ASTM requirements

Oxygen Flow Rate :

• 1 L/h ± 0.1 L/h per sample

Bath Medium :

• White technical oil

Bath Capacity :

• 7.2 US gallons (27.2 L)

Bath Construction :

• Double-wall insulated stainless steel

Temperature Control :

• Microprocessor-based control
• Digital setpoint and temperature display
• °C/°F selection
• Automatic overtemperature cut-off

Standard Accessories :

• Six oil receptacles
• Six independent flowmeters mounted on a common manifold

Optional Accessories :

• Bath thermometer
• Drying tower
• Catalyst

Applicable Standard :

• ASTM D2440

• Capacity for six oil samples
• Digital temperature control with digital display
• Switchable temperature display in °C and °F
• Independent oxygen flowmeters for all six samples
• Common manifold for oxygen distribution
• Double-wall insulated stainless steel bath
• Automatic overtemperature cut-off protection
• Maintains the required sample immersion depth
• Designed to meet applicable ASTM test requirements
