Oxidation Stability Test Apparatus for Gasoline and Aviation Fuels for Petroleum Testing Equipment

The Gasoline and Aviation Fuel Oxidation Stability Test Apparatus is designed to evaluate the tendency of gasoline and aviation fuels to form gum during storage. The sample is oxidized inside a stainless steel pressure vessel initially charged with oxygen at 100 psi (689 kPa) and heated under controlled conditions.

For gasoline, the test determines the time required for a specified pressure drop. For aviation fuels, it measures the gum and precipitate formed after a specified aging period.

The apparatus is available in water or liquid bath and solid block bath configurations. The liquid bath models feature insulated stainless steel tanks, support racks, port covers, and temperature control systems. The solid block models use insulated aluminum blocks with microprocessor-based temperature control, overtemperature protection, and dual LED displays for actual and setpoint temperatures.

Manufactured by Atico Export for reliable oxidation stability testing and quality assessment of gasoline and aviation fuels.

Applications :

• Evaluation of gasoline oxidation stability
• Assessment of aviation fuel oxidation stability
• Determination of pressure drop during gasoline testing
• Measurement of gum and precipitate formation in aviation fuels
• Fuel storage stability evaluation
• Quality control and research in petroleum testing laboratories

A. Water / Liquid Oxidation Baths

Capacity :

• Two test vessels
• Six test vessels

Temperature Range :

• Ambient to 221°F (105°C)

Bath Medium :

• Two-vessel model: 9.9 US gallons (37.5 L) of water or white technical oil
• Six-vessel model: 16.1 US gallons (60.9 L) of water or white technical oil

Construction :

• Double-wall insulated stainless steel tank
• Support racks and port covers
• Overflow standpipe and drain
• Plated brass reflux condenser

Power Supply :

• 115 V, 60 Hz, 19 A — two-vessel configuration
• 220–240 V, 50/60 Hz, 10 A — two-vessel and six-vessel configurations

B. Solid Block Oxidation Baths

Capacity :

• Two test vessels
• Four test vessels

Temperature Range :

• Ambient to 250°F (121°C)

Temperature Control :

• Microprocessor-based control
• Dual LED displays for actual and setpoint temperatures
• °C/°F temperature display
• Built-in overtemperature protection

Construction :

• Insulated aluminum block
• Insulated steel cabinet
• Chemical-resistant polyurethane enamel finish
• Lids for pressure vessel ports

Power Supply :

• 115 V, 60 Hz, 12 A — two-vessel configuration
• 220–240 V, 50/60 Hz, 6 A — two-vessel configuration
• 115 V, 60 Hz, 22 A — four-vessel configuration
• 220–240 V, 50/60 Hz, 11 A — four-vessel configuration

• Available in liquid bath and solid block configurations
• Liquid bath models available in two-unit and six-unit capacities
• Solid block models available in two-unit and four-unit capacities
• Low liquid level controllers on liquid bath models
• Digital touch-screen temperature controller on the six-unit liquid bath
• Microprocessor-based temperature control for solid block models
• Digital temperature displays in °C and °F
• Automatic overtemperature protection
• Double-wall insulated construction on liquid bath models
• Stainless steel tanks, support racks, and port covers
• Overflow standpipe and drain to maintain the required liquid depth
• Plated brass reflux condenser to minimize evaporation loss
• Insulated aluminum block construction for solid block models
• Solid block design provides an alternative to boiling water baths
• Thermometer supplied separately
