Oxidation Stability Test Apparatus for Lubricating Greases for Petroleum Testing Equipment

The Oxidation Stability Test Apparatus is designed to evaluate the oxidation stability of lubricating greases under controlled temperature and oxygen pressure conditions. The sample is placed inside an oxidation bomb initially charged with oxygen at 110 psi (758 kPa) and maintained at an elevated temperature for a specified aging period. The pressure drop inside the bomb is measured using a pressure gauge or pressure transducer to assess oxidation stability.

The system consists of a stainless steel oxidation bomb, pressure measurement equipment, and a constant-temperature bath. The oxidation bomb features polished internal surfaces for easy cleaning and is designed to withstand a working pressure of 180 psi (1241 kPa) at 99°C (210°F).

The temperature-controlled bath accommodates four oxidation bombs at the required immersion depth. It features a digital touch-screen controller, overtemperature protection, and a stainless steel interior with a bomb support rack and overflow/drain arrangement.

Manufactured by Atico Export for reliable oxidation stability testing of lubricating greases in petroleum and lubricant testing laboratories.

• Oxidation stability testing of lubricating greases
• Evaluation of pressure drop during accelerated oxidation
• Assessment of lubricant resistance to oxidation
• Quality control and research in lubricant testing laboratories

Oxidation Bomb :

• Material: Stainless steel
• Initial oxygen charging pressure: 110 psi (758 kPa)
• Working pressure: 180 psi (1241 kPa) at 99°C (210°F)
• Construction: Body, lid with stem and needle valve, and dish holder
• Seals: Three PTFE gasket seals
• Fasteners: Cap screws supplied with wrench

Pressure Measurement Equipment :

• Pressure range: 0–160 psi (0–1100 kPa)
• Graduation: 1 psi intervals
• Accuracy: Better than 0.5 psi (3.45 kPa)
• Pressure measurement options: Mechanical gauge or pressure transducer
• Pressure gauge cleaned for oxygen service

Oxidation Bath :

Capacity :

• 4 oxidation bombs

Temperature Range :

• Ambient to 221°F (105°C)

Temperature Control Stability :

• Exceeds applicable ASTM requirements

Bath Medium :

• Water or white technical oil

Bath Capacity :

• 7.2 US gallons (27.2 L)

Temperature Control :

• Digital touch-screen controller
• Actual and setpoint temperature display in °C or °F
• Redundant overtemperature cut-off protection

Bath Construction :

• Heavily insulated welded stainless steel interior
• Bomb support rack
• Overflow standpipe and drain
• Steel exterior with corrosion-resistant polyurethane enamel finish

Standard Accessories :

• Stainless steel oxidation bomb
• Three PTFE gasket seals
• Cap screws and wrench

Optional Accessories :

• Mechanical pressure gauge
• Pressure transducer or digital pressure management system
• Additional fluorocarbon seals

• Stainless steel oxidation bomb
• Polished internal surfaces for easier cleaning
• Needle valve for oxygen charging and pressure control
• PTFE gasket seals for secure sealing
• Mechanical pressure gauge or pressure transducer options
• Pressure measurement accuracy better than 0.5 psi (3.45 kPa) for the specified gauge
• Digital touch-screen temperature controller
• Rapid temperature stabilization with minimal overshoot
• Redundant overtemperature protection circuit
• Digital display of actual and setpoint temperatures in °C or °F
• Insulated stainless steel bath interior
• Bomb support rack for correct immersion depth
• Overflow standpipe and drain
• Corrosion-resistant polyurethane enamel finish on the steel exterior
