Pan Type Concrete Mixer

For AECE2562/A, AECE2562/B, AECE2562/C, AECE2562/D and AECE2562/E models, the mixing pan is removable and this allows easy access to the pan and emptying after completion of the mixing operation.
For AECE2562/B and AECE2562/C models, ease in discharge operation is provided thanks to the movable pan.
Double Engine Models enable more homogeneous mixtures to be prepared in a shorter time than Single-Engine Models. These models have a second motor that rotates the mixing paddles in the opposite direction to the pan-type hopper rotation direction.
The speed of the pan can be adjusted in the Double Engine, Frequency Controlled (Pan speed controlled) models.
The speed of the pan and mixing blade can be adjusted in the Double Engine, Frequency Controlled (Pan and mixing blade speed controlled) models.
All parts of the IP55 protected mixer are non-corrosive painted and galvanized.

Application :

• The efficient mixing of concrete is essential if quality specimens are to be manufactured. Pan type mixers are suitable for mixing concrete in the laboratory.
• The mixers are designed to give efficient mixing of both dry and wet materials.

Dimensions (cm) :

• AECE2562/A - 93 ° 97 ° 122
• AECE2562/B - 118 ° 140 ° 140
• AECE2562/C - 118 ° 140 ° 140
• AECE2562/D - 100 ° 100 ° 135
• AECE2562/E - 100 ° 100 ° 135
• AECE2562/F - 100 ° 100 ° 135

Weight (kg) :

• AECE2562/A - 245
• AECE2562/B - 280
• AECE2562/C - 280
• AECE2562/D - 260
• AECE2562/E - 260
• AECE2562/F - 260
