Particle Size Sedimentation Hydrometer Method

Usage :

• Used to determine the quantitative size distribution of very fine particle in soils such as clay and silt.

Construction :

• Solid-Robust Construction

Sedimentation Cylinder :

• Capacity : 1000 ml (6 Nos.) with rubber bungs.

Soil Hydrometer :

• Range : 0.995 to 1.038 g/ml with div. 0.001

Tank :

• Size : 600 x 300 x 380 mm approx.

Heater :

• With Thermostat Control

Power Consumption :

• 1000 W

Thermometer :

• Glass type, Range : -10 to 50° C., Sub-div. 0.5° C.

Beaker :

• Material : Borosilicate Glass, Capacity : 250 ml

Stirrer :

• Speed : 4000 RPM approx.

Accessories :

• Baffle Cup, for dispersing soil-particles in water

Standards Compliance :

• ASTM D 422 AASHTO T 88, BS 1377-2.
