Photoelectric Detection Principle Physics Lab Experiments Setup by ATICO EXPORT

This experiment system is designed for the study of photoelectric detection principles and applications. The system consists of a main control unit with optional optical and electronic modules. Its modular PCB design incorporates functional units such as a light source drive module, pulse drive module, model testing module, and light source indication module. The instrument offers convenient operation, intuitive experimental observation, and serves as an effective platform for understanding photoelectric detection technologies and measurement techniques.

Physics Lab Experiments from Atico Exports.

Experimental Principle and Content

• Study of photoelectric detection principles
• Investigation of optical-to-electrical signal conversion
• Analysis of photoelectric sensor characteristics
• Measurement of electrical parameters in photoelectric systems
• Study of light source driving and signal processing techniques
• Understanding pulse-driven photoelectric circuits
• Development of practical skills in photoelectric measurement and instrumentation

Host :

• Main Chassis Size: 520 mm × 318 mm × 145 mm

Voltmeter :

• 3½-Digit Display
• Four Selectable Ranges: 0–200 mV, 0–2 V, 0–20 V, 0–200 V

Ammeter :

• 3½-Digit Display
• Four Selectable Ranges: 0–200 μA, 0–2 mA, 0–20 mA, 0–200 mA

Illuminometer :

• Resolution: 0.1 lx
• Measurement Ranges: 200, 2000, 20000, 50000 Lux
• Sampling Rate: 1.5 Times/Second

Display :

• 1999-Count LCD Display

Weight :

• Approx. 5 kg
