Physics Demonstration kit Optical bench Basic collection for Lab Use in Schools & Colleges ATICO Export

For demonstrating fundamental laws of light. The kit contains all the individual components and equipment needed for investigating the propagation of light, reflection of light, refraction of light, and dispersion of white light into its component colours.
The design and function of the human eye, along with commonly used optical instruments, are illustrated and investigated through experiments.

Included Items :

• 1 × Plastic case approx. 540x450x150 mm
• 1 × Foam insert, grey, knobbed, 515x360x30 mm
• 1 × All-purpose rail, 1000 mm
• 5 × Rider with clamping tube, 30 mm
• 1 × Lens in frame, biconvex with rod, f = +100 mm
• 1 × Lens in frame, biconvex with rod, f = +200 mm
• 1 × Lens in frame, biconcave with rod, f = -100 mm
• 1 × Colour filters, primary red, green, blue
• 1 × Screen and mirror support on rod
• 1 × Screen, white/black with rod
• 1 × Screen, ground glass, 90x90 mm
• 1 × Colour slide
• 1 × Colour slide, microscopic preparation
• 1 × Plane-parallel plate, magnetic adhering
• 1 × Optical model, half cylinder, magnetic adhering
• 2 × Diaphragm and slide holder
• 1 × Hole diaphragm, 1 mm diameter
• 1 × Hole diaphragm, 2 mm diameter
• 1 × Hole diaphragm, 4 mm diameter
• 1 × Slit diaphragm, 1 slit
• 1 × Slit diaphragm, 3 slits
• 1 × Cover diaphragm
• 1 × Slide with arrow motif
• 1 × Prism, equilateral, 42x32 mm, 3×60°
• 1 × Plastic box, 61x54x54 mm
• 1 × Cuvette
• 1 × Foam insert, 515x365x110 mm
• 1 × Storing diagram
• 1 × Lens in frame, biconvex with rod, f = +50 mm
• 1 × Prism table
• 1 × Shadow ball on rod
• 1 × Optics lamp with quartz-iodine bulb, 12 V / 50 W
• 1 × Pair of adjustable feet for rails

Size of kit :

• 540 × 450 × 150 mm
