Physics Demonstration kit Solar thermal energy conversion for Lab Use in Schools & Colleges ATICO Export

For demonstrating the fundamentals and technical applications of solar thermal energy conversion.
This kit contains apparatus for experiments on heat absorption, convection, and radiation, and allows the assembly of a complete solar collector system with thermosyphon recirculation, pump circulation, and heat exchanger.

Solar Collector :

• Converts solar radiation into heat using water as the energy transfer medium
• Enables measurable temperature rise after exposure to light
• Used with a reflector lamp acting as the energy source
• Includes removable front glass panes to reduce convection losses
• Features a blackened collector spiral with six loops and quick-release hose connectors
• Includes interchangeable black and white rear covers, insulation, and removable rear pane

Heat Exchanger with Pump Circulation :

• Transfers thermal energy between liquids
• Consists of copper tubing coil in a transparent vessel
• Circulation supported by a connected pump

Thermosyphon Circulation :

• Utilizes density differences in water due to temperature changes
• Enables natural convection and circulation through connected hoses and elevated tank

Included Items :

• 1 × Stand rod, 500x10 mm Ø, stainless steel
• 2 × Stand rod, 250x10 mm Ø, stainless steel
• 1 × All-purpose rail, 500 mm
• 1 × Convection tube, 250x150 mm
• 1 × Reflector lamp, 175 W
• 1 × Metal plate with clip, black
• 1 × Metal plate with clip, white
• 1 × Lid
• 1 × Plug-in sleeve with reducing disk
• 1 × Lamp holder ES on rod with mains cable and switch
• 1 × Plastic tube, 90 mm
• 2 × Rubber stopper 18/14 mm, 1 hole 5 mm Ø
• 1 × Pair of feet for rails
• 1 × Tray, 510x360x20 mm
• 1 × Plastic case approx. 540x450x150 mm
• 1 × Lid foam, grey, 515x355x10 mm
• 1 × Cable fixer, velcro
• 1 × Colouring agent, red (for lab use only)
• 1 × Matches (10 cases)
• 1 × Tripod stand, 80 mm
• 1 × Table, small, 180x110 mm
• 2 × Holding clip on rod, right angled, 15 mm Ø
• 2 × Rider with clamping tube, 75 mm
• 1 × Metal plate, 150 mm Ø
• 2 × Digital thermometer, 210x40 mm, -50 to +300°C
• 1 × Elevated tank with two hoses
• 1 × Heat exchanger vessel with tubing and plug closure
• 1 × Solar collector with rod (demo model)
• 1 × Spirit burner, metal
• 1 × Power supply unit, 6 V / 1 A DC
• 2 × Bosshead, double
• 1 × Holder
