Physics Electricity Dynamo generator for Lab Use in Schools & Colleges ATICO Export

To fulfil the requirements of experimental use, the generator is designed to operate manually and safely under various conditions.
It can produce up to 8 V when hand-operated, while typical operation by students generates 3–4 V, suitable for standard bulbs without risk of burnout.
The construction ensures high mechanical stability, allowing safe operation even under short-circuit conditions.
It supports loads up to approximately 10 A and enables energy conversion in the range of 2 to 60 W with clearly perceptible effort.
Low friction allows small changes in energy consumption to be easily observed.
The unit consists of an electric motor with a low-noise gearbox, housed in a transparent casing with 4 mm socket terminals, crank, pulley, and mounted on a metal rod.

Rated voltage :

• 12 V

Idling speed :

• 15,000 rpm

Idle current :

• 0.7 A

Rated speed :

• 13,000 rpm

Rated current :

• 4 A

Rated torque :

• 2.5 N/cm

Output :

• 67 W

Gear Box :

Transmission ratio :

• 1:33

Mounting rod :

• 180 × 10 × 10 mm
