Physics Electricity High Power Van De Graff Generator for Lab Use in Schools & Colleges ATICO Export

For producing high electric charges for electrostatic experiments.
The unit features a large nickel-coated stainless steel sphere with 4 mm sockets for connecting equipment, a belt guide in a transparent tube, and a plastic base with an earth socket.
It also includes a halogen lamp for drying the belt and a connection box with on/off switches for the motor and lamp. Supplied ready assembled.

Accessories Included:

• Stainless steel sphere, nickel-coated, 100 mm diameter
• Stainless steel sphere on rod, 300 × 12 mm diameter, with earth lead
• Bunch of threads with 4 mm plug pin
• Pointed wheel with needle-point base
• Dust-protection cover
• Power supply with connecting leads

Electric charge :

• 100 to 150 kV (depending on room humidity)

Short circuit current :

• approx. 6 µA

Sphere diameter :

• 270 mm

Operating voltage :

• 230 V / 50 Hz

Dimensions :

• 720 × 325 × 225 mm

Mass: approx. :

• 4 kg
