With the newly developed digital timer and its accompanying light barriers MEKRUPHY GMBH is setting new standards for classical mechanics measurements
Not only in the areas of kinematics and dynamics, but also for the topics of energy, momentum and mechanical oscillations
This new measuring method makes it possible for students to conduct satisfying experiments on the laws of collisions and the conservation of momentum
Universal track:
The track is used here both as a track and as a stand
It is not included with the set since it is also used by other experiment sets
Differences from MECHANICS 3:
The MECHANICS 3 plus experiment set differs from the standard MECHANICS 3 set in that it contains:
An additional dynamics trolley
A mounting peg
Another flag
A roll of string
Razor blades with a safe grip
With this supplement used in conjunction with the MECHANICS 2 set, experiments on the conservation of momentum and the laws of elastic and inelastic collisions can be carried out easily and with high precision
See also MECHANICS 5:
Supplementary computer-based experiments on mechanics are provided by the MEKRUPHY experiment set MECHANICS 5
Included items:
Storage case
Inlay with cut-outs for apparatus, A+
2 Photogates
Digital timer
2 Track supports, A3
Cord, 100 cm, in box
Balls in box
2 Flags
Coil spring, 3 N/m
Coil spring, 10 N/m
Dynamics trolley, A2
Pulley with rod
Rod with hook, 7 cm
Steel ball, 20 mm diam.
Mounting pin
Wooden pendulum bob
Steel pendulum bob
Drop plate
Pulley holder
Spool of thread
5 Razor blades with grip
Cord, 22.6 cm, in box
2 Riders for photogate
2 Holders for photogate
Spring bumper, A2
Additionally required:
Experiment set MECHANICS 2
Universal track
Experiments:
A3-1: How long is a second?
A3-2: Personal reaction times
A3-3: Frames of reference
A3-4: Uniform motion
A3-5: Instantaneous velocity
A3-6: Uniformly accelerated motion
A3-7: Free fall
A3-8: Horizontal projectile launch
A3-9: Force and acceleration
A3-10: Mass and acceleration
A3-11: Coil spring pendulums 1
A3-12: Coil spring pendulums 2
A3-13: String pendulums
A3-14: The law of conservation of energy in mechanics
