Physics Mechanics Liquids and Gas Science Kits for Lab Use in Schools & Colleges ATICO Export

BOYLE’s law and GAY-LUSSAC’s law in an experiment carried out by student themselves:

• Experiments on Boyle’s law and Gay-Lussac’s law can be carried out with high precision and simplicity by students themselves

• This alone makes the set highly valuable

• Experiments on pressure at depth, buoyancy and hydraulic presses are also impressive and fascinating

• The two glass piston probes with ground glass heads ensure highly accurate measurement results

• Glass components are stored in shaped cut-aways in the case inlay and should be placed back after use and cleaning

• Experience shows that allowing students to perform experiments themselves results in fewer breakages than teacher demonstrations

Keeping your workplace dry:

• The storage case (11 cm tall) also serves as a watertight trough
• Stand rods can be screwed into the case as needed
• The workbench remains dry during water-based experiments
• Even with the artesian well fountain, everything outside the case stays dry
• The case can be easily emptied and dried using paper towels

Included items:

• 1 × Storage case
• 1 × Inlay with cut-outs for apparatus, A4
• 1 × Digital thermometer, EN (-40°/+70°C)
• 1 × Plastic beaker, 250 ml
• 2 × Universal clamps
• 2 × Bosshead clamps, A2
• 1 × Glass funnel
• 1 × Steel cylinder, A1
• 1 × Test tube, 12 x 100 mm
• 1 × Glass tube, 250 mm
• 1 × Piston probe, 10 ml
• 1 × Piston probe, 20 ml
• 1 × Plastic beaker, 50 ml
• 1 × Piston head A
• 1 × Piston head B
• 2 × One-way valves
• 1 × Silicon tube, 7 mm diam. x 250 mm
• 1 × Plastic tube with lock fitting
• 1 × Adapter w/w
• 1 × Perspex tube, A4
• 1 × Force gauge, 2 N
• 1 × Stand rod, P3
• 1 × Cord, 40 cm, in box
• 1 × Pipette with bulb
• 1 × Measuring tape, 2 m
• 4 × Weights, 50 g, with slot
• 5 × Weights, 10 g, with slot
• 1 × Plastic plate, round, A4
• 1 × Container with screw cap, 10 ml
• 1 × Pressure vessel
• 1 × Manometer tube

Additionally required:

• For the experiments marked with *, a set of scales are needed

Experiments:

• A4-1: Behaviour of liquids and gases under pressure
• A4-2: The aneroid manometer
• A4-3: Hydrostatic pressure
• A4-4: The cause of hydrostatic pressure
• A4-5: Connected vessels
• A4-6: The artesian well
• A4-7: Buoyancy
• A4-8: Buoyancy force and counterforce
• A4-9: Floating, hovering, sinking
• A4-10: Determining density with the buoyancy method
• A4-11: Circular area and diameter
• A4-12: The hydraulic press*
• A4-13: Effects of air pressure
• A4-14: The Boyle-Mariotte law*
• A4-15: The Gay-Lussac law

Additionally required:

• For the experiments marked with *, a set of scales are needed
