Physics Students kit Electrical circuits for the steel board for Lab Use in Schools & Colleges ATICO Export

The bases for components are magnetically attachable and printed with the relevant circuit symbols and wiring. They can be placed horizontally on a bench or attached vertically to a steel board.
The electrical components are mounted inside open sockets and are not visible from above. All bases are equipped with 4 mm sockets.
The power supply component includes a battery compartment for two cells and a low-voltage socket for an alternative plug-in power supply connection.

Experiments :

• Simple circuit with lamp
• Circuit with lamp and switch
• Series/parallel circuit with two lamps
• Electrical conductors and non-conductors
• Logic AND
• Logic OR

Included Items :

• 1 × Bulb 2.5 V / 0.2 A (10 pcs.)
• 1 × Material patterns, set of 14 pcs.
• 2 × Plug lead, 25 cm, black
• 4 × Plug lead, 10 cm, black
• 1 × Set of 4 cells, 1.5 V
• 1 × Test stand element, magnetic adhering
• 2 × Switch element, magnetic adhering
• 1 × Plastic box 320x245x50 mm
• 1 × Power supply element 3 V, magnetic adhering
• 2 × Bulb holder element MES, magnetic adhering

Size of bases :

• 120 × 90 mm

Size of kit :

• 330 × 275 × 55 mm
