Physics Tellurium Model for Lab Use in Schools & Colleges ATICO Export

This model demonstrates the Earth–Sun–Moon system using an innovative Fresnel lens to create a bright, parallel light beam that fully illuminates the globe Clearly shows day and night, seasons, and the apparent movement of the sun between the tropics. Additional features allow demonstration of lunar phases, eclipses, and the position of the sun using a horizon disc with a shadow pin

Key Features :

Fresnel Lens System :

• Produces a bright, parallel light beam
• Clearly displays day/night boundary on the globe
• Enables focused light point to show sun’s movement between tropics

Three Operating Modes :

• Day and night / seasons
• Tropics (sun-point movement across equator)
• Lunar phases and eclipses

Horizon Disc with Shadow Pin :

• Demonstrates sun position using shadow
• Can be placed anywhere on the globe

Satellite Rod :

• Demonstrates position and motion of a geostationary satellite

Moon on Telescopic Rod :

• Adjustable to show lunar phases and eclipses

Date Disc and Pointer :

• Shows seasonal changes (solstices and equinoxes)
• Earth’s axis inclination visualized

Earth Globe :

• Large and clearly visible from distance
• Mounted on telescopic rod to show axis orientation

Included Items :

• 1 × Felt pen, water soluble
• 1 × Dust cover with bag

Globe diameter :

• 15 cm

Lens diameter :

• 16 cm

Lamp :

• 12 V / 20 W quartz-iodine

Size :

• 720 × 370 × 250 mm

Mass :

• approx. 4 kg
