Pin on Disc Tester for Oil Fuel and Petroleum Testing Instruments

The Pin-on-Disc Tester determines the wear and friction characteristics of materials during sliding contact under nominally non-abrasive conditions. It is designed to evaluate the tribological properties of material pairs under dry or lubricated conditions. During testing, a stationary pin mounted in a holder contacts a rotating disc at a specified speed and normal load. The resulting frictional force is measured, while real-time data acquisition enables the analysis of friction, wear, and temperature. The system is suitable for testing metals, polymers, composites, ceramics, lubricants, cutting fluids, abrasive slurries, coatings, and heat-treated materials. Data acquisition software records relevant test parameters, including pin pressure, pin temperature, sliding speed, and lubrication conditions. Custom configurations are available for different testing requirements. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for tribology, friction, and wear testing applications.

• Wear analysis of materials under sliding contact
• Friction and tribological testing under dry or lubricated conditions
• Testing of metals, polymers, composites, ceramics, and coatings
• Evaluation of lubricants, cutting fluids, and abrasive slurries
• Testing of heat-treated materials

Disc Rotation Speed:

• 100–2000 rpm

Maximum Normal Load:

• 200 N

Frictional Force:

• 0–200 N

Wear Measurement Range:

• 4 mm

Pin Size:

• 3–12 mm diagonal/diameter

Disc Size:

• 60 mm diameter × 8 mm thick

Wear Track Diameter:

• 0–140 mm

Data Acquisition System:

• Real-time measurement of physical properties
• Friction, wear, and temperature analysis
• Recording of pin pressure, pin temperature, sliding speed, and lubrication parameters
• Data acquisition hardware and software

Standard Accessories:

• Electronic controller
• Connecting cables
• Spare fuses: 2
• Set of weights
• Set of hand tools
• Set of pins
