The Pipe Cleaning Training Unit, simulates a real house piping system, so original components used in plumbing systems are employed.
Technical Specifications
ATENG 12787 — Pipe Cleaning Training Unit
The “ATENG 12787” unit consists of:
Anodized aluminum frame and panels made of painted steel.
The unit includes wheels to facilitate its mobility.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
Ten hose connections with quick-release couplings.
Four closable intakes to pour the contaminants.
Two cold water intakes.
Toilet tank.
Safety elements of the system:
Bleed valve.
Hot water safety valve: up to 70 °C.
Thermostatic automatic mixer:
Minimum flow rate: 300 l/h.
Maximum pressure: 1 – 5 bar.
Safety stop for a maximum temperature of 70 °C.
Two-handle mixer.
Hot water boiler simulator.
Sewage line.
Pipes:
Copper.
Sections made of PMMA for inside visualization.
