PLANE FRAME

A standard truss made from fully welded hollow square section steel members, with dual end bearings allowing it to be mounted normally or inverted.

• Span: 3.6 m, four-bay plane frame
• Diagonal angle: 45°
• Section: 40 × 40 mm hollow steel tube, approx. 3 mm wall thickness
• Maximum load: 40 kN
