Planetary Ball Mill (Net weight – 86 kg)

The Planetary Ball Mill (Net weight – 86 kg) is a powerful benchtop model with a single grinding station and an easy-to-use counterweight which compensates masses up to 8 kg. It allows for grinding up to 220 ml sample material per batch.
The extremely high centrifugal forces of Planetary Ball Mills result in very high pulverization energy and therefore short grinding times.
The Planetary Ball Mill (Net weight – 86 kg) can be found in virtually all industries where the quality control process places the highest demands on purity, speed, fineness and reproducibility.

The mill is ideally suited for tasks in research like mechanochemistry (co-crystal screening, mechano-synthesis, mechanical alloying and mechanocatalysis), or ultrafine colloidal grinding on a nanometer scale, as well as for routine tasks such as mixing and homogenizing soft, hard, brittle or fibrous materials.

THE IDEAL BALL MILL FOR STANDARD APPLICATIONS

• Max. speed 650 rpm
• Up to 10 mm feed size and 0.1 °m final fineness
• 1 grinding station for jars from 12 ml up to 500 ml
• Jars of 12 – 80 ml can be stacked (two jars each)
• GrindControl to measure temperature and pressure inside the jar.
• Aeriation lids to control the atmosphere inside the jar
• Storable SOPs and cycle programs, 5 different jar materials for dry and wet grinding

Applications :

• pulverizing, mixing, homogenizing, colloidal milling, mechanical alloying, mechanosynthesis, nano grinding, co-crystal screening

Field of application :

• agriculture, biology, chemistry, construction materials, engineering / electronics, environment / recycling, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals

Feed material :

• soft, hard, brittle, fibrous - dry or wet

Size reduction principle :

• impact, friction

Material feed size :

• < 10 mm

Final fineness :

• < 1 °m, for colloidal grinding < 0.1 °m

Batch size / feed quantity :

• max. 1 x 220 ml, max. 2 x 20 ml with stacked grinding jars

No. of grinding stations :

• 1

Speed ratio :

• 1 : -2

Sun wheel speed :

• 100 - 650 min-1

Effective sun wheel diameter :

• 141 mm

G-force :

• 33.3 g

Type of grinding jars :

• EasyFit, optional areation covers, safety closure devices

Material of grinding tools :

• hardened steel, stainless steel, tungsten carbide, agate, sintered aluminum oxide, silicon nitride, zirconium oxide

Grinding jar sizes :

• 12 ml / 25 ml / 50 ml / 80 ml / 125 ml / 250 ml / 500 ml

Stackable grinding jars :

• 12 ml / 25 ml / 50 ml / 80 ml

Adapter for single-use glas vials :

• 24 x 1.5 ml / 7 x 20 ml

Setting of grinding time :

• digital, 00:00:01 to 99:59:59

Interval operation :

• yes, with direction reversal

Interval time :

• 00:00:01 to 99:59:59

Pause time :

• 00:00:01 to 99:59:59

Storable :

• SOPs 10

Interface :

• RS 232 / RS 485

Drive :

• 3-phase asynchronous motor with frequency converter

Drive power :

• 750 W

Electrical supply data :

• different voltages

Power connection :

• 1-phase

Protection code :

• IP 30

Power consumption :

• ~ 1250W (VA)

W x H x D closed :

• 640 x 480 (780) x 420 mm

Net weight :

• ~ 86 kg

Standards :

• CE

Patent / Utility patent :

• Counter weight (DE 20307741), FFCS (DE 20310654), SafetySlider (DE 202008008473)
