Plate Bearing Equipment

To determine the static deformation of flexible road pavement in the centre of the loading plate, the bearing capacity and deflection of subgrade and subbase of roads. Used with the Benkelman Beam Apparatus.

Plate Bearing Equipment Components

Plate Bearing Equipment consists of Bearing plate 600 mm diameter cast aluminium, Piston assembly 200 kN capacity, Hydraulic hand pump, High Pressure Hose and Connection Apparatus and Analog manometer.

Digital Plate Bearing Equipment Components

Digital Plate Bearing Equipment consists of Bearing plate 600 mm diameter cast aluminium, Piston assembly 200 kN capacity, Hydraulic hand pump, High Pressure Hose and Connection Apparatus, Analog Manometer, Pressure Transducer and Battery Operated Digital Readout Unit.

STANDARDS COMPLIANCE :

• COMPLIED AS PER NF P94-117-1

Weight (kg) :

• Plate Bearing Equipment - 100
• Digital Plate Bearing Equipment - 102

Spare Parts & Accessories :

Capacity :

• Bearing Plate 600 mm
• Piston Assembly 200 kN
• Hydraulic Hand Pump 700 bar
