PLC USED:
- PLC without display
- Number of discrete inputs/outputs: 14 In / 10 Out
- High-speed frequency inputs: 10
- 12/24V DC relay
- Relay maximum resistive load rating: 2 Amps at 24 VDC and 220 VAC
- Output control voltage: Transistor output
- Expandable with extra module
- Programming software: Connected component programming software
EXPANDABLE MODULE
- 2-channel analog input module
- Input rating: Current: 0–20mA
2-CHANNEL ANALOG OUTPUT MODULE
- Output rating: Voltage: 0–10V
INPUT-OUTPUT PLUG-IN MODULE
- Number of inputs/outputs: 4 in / 4 out
- Resistive load rating: 2 Amps at 24 VDC and 220 VAC
- Output control voltage: Transistor output
SPECIFICATIONS
Power Supplies:
- DC power supply (SMPS based): +24V DC, 5A
- DC power supply (IC regulated): 0–10V, 250mA (for analog input)
- Operated on mains power: 230V, 50Hz ±10%
Components Mounted on the Panels:
- Buzzer
- Indicator
- Relay
- Fuse
- Variable resistor: 10K Ohm
- 14 data switches
- 10 LED indicators with fuse
- Digital meter (voltmeter and ammeter)
Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.
