PLC Trainer Versamax

PRODUCT NAME:

• PLC Trainer

ABOUT PLC:

• 12/24 VDC input
• 8 relay outputs, 2.0 Amps
• 24V DC power supply

NUMBER OF DISCRETE INPUTS/OUTPUTS:

• 12 Inputs / 8 Outputs
• Supports 4 expansion units

NUMBER OF ANALOG INPUTS/OUTPUTS:

• Supports up to 4 analog expansion units
• Up to 16 analog inputs / 8 analog outputs

PHYSICAL I/O MAXIMUM:

• 132

USER PROGRAM LOGIC MEMORY:

• 24 K

REGISTERS:

• 32 K

ANALOG POTS FOR DATA ADJUSTMENT:

• No

SERIAL PORT CONNECTOR:

• RJ-45 and optional DB-15
• RS-232, RS-485, and Ethernet communication

PROTOCOLS:

• SNP and SNPX
• RTU Master and Slave
• Serial communication protocols
• Ethernet communication protocols
• TCP server and tunneling

POWER VOLTAGE:

• 24 VDC

INPUT POWER SUPPLY RATING:

• 10 Watts

INPUT DEVICE VOLTAGE:

• 24 VDC

MAXIMUM TYPE A AND B COUNTERS:

• N/A

OUTPUT CONTROL VOLTAGE:

• Relay Output

RELAY MAXIMUM RESISTIVE LOAD RATING:

• 2 Amps at 24 VDC and 240 VAC

MAXIMUM NUMBER OF PWM/PULSE OUTPUTS:

• 4 Type A and 1 Type B at 100 kHz (32 bit)

24 VDC USER POWER FOR SENSORS:

• 435 mA

DIMENSIONS (W × H × D):

• 150 × 90 × 76 mm

PROGRAMMING SOFTWARE:

• PLC programming software

Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.
