Understand the principles, operational theory and maintenance of ABS in air brake systems found on trucks or large vehicles or buses
Understand original components are used in the trainer and feature quick connection couplings with color-coded pneumatic hoses for easy examination
Understand ABS control unit functions of electrical circuit is micro-controller system used to operate outputs to air brake ABS modulator valves
Understand a color chart showing the brake system circuit is mounted onto the trainer for reference
Understand the main components are attached to panels which are mounted on a mobile trolley and individual wheel speed detection is simulated using electric motor driven ABS wheel sensor assembly
Understand the ABS speed sensor sends the speed signal to ABS control unit which is then processed and sends control signal to output modulator valve to control braking torque in individual brake actuators
Understand the trainer is complete with a comprehensive graphical training manual covering all aspects of air brake and ABS theory and functional technologies, student experiments for system configurations, diagnostics, and ABS simulations of fault conditions
