Pneumatics & Electro-Pneumatics Trainers

• Advanced pneumatics and electro pneumatics trainer composed of industrial grade components commonly used in industrial field
• Classified into basic level for knowledge and control methods and advanced level for higher control
• Customizable in modular format for logical analysis of electrical circuits
• Design and wiring in pneumatics and electro pneumatics training experiments
• Includes electric control for pneumatic sequence control
• Expansion and compatibility supported with 4 mm binding post banana socket
• Sensor protection circuit integrated for safety
• Uses standard plug in profile panel board for training setup
• Each part can be attached and detached horizontally or vertically without tools

Pneumatics Components :

Modular profile panel board 600 mm x 700 mm :

• 140 rubber grommet profile plug points
• Air manifold 6 x quick coupler pressure port

Air service unit with pressure regulator, gauge, filter, lubricator and shut off valve :

Pressure regulator with gauge

Pressure gauge

Double acting cylinder 25 mm x 100 mm

Single acting cylinder 25 mm x 50 mm

3/2 way push button spring return valve

5/2 way push button spring return valve

5/2 way roller spring return valve

• Valve left x 1, right x 1

3/2 way push pull knob bistable valve

5/2 way push pull knob bistable valve

3/2 way pull knob hand lever valve

5/2 way pull knob hand lever valve

3/2 way single pilot spring return valve

5/2 way single pilot spring return valve

5/2 way double pilot bistable valve

AND valve

Shuttle valve OR valve

One way flow control valve throttle valve

Quick exhaust valve

Quick coupler plug

T joint

Hose

• Diameter 4 mm
• Length 5 m

Electro-Pneumatics Components :

3/2 way single solenoid spring return valve 24 VDC

5/2 way single solenoid spring return valve 24 VDC

5/2 way double solenoid valve 24 VDC

Electrical roller limit switch N.O. and N.C.

• Switch left x 1, right x 1

Relay 24 VDC

• 4 contacts N.C. and N.O.

Timer 24 VDC

Electrical push button module

• Contacts N.O. x 1, N.C. x 1

Electrical push button module

• Contacts N.O. x 2

Electrical push button module

• Contacts N.C. x 2

Electrical selector switch module

• Contacts N.O. x 1, N.C. x 1

Power diodes 1 x 2

Indicator lamps 1 x 2

Buzzer 24 VDC

Portable power supply unit 24 VDC

• Dimensions 215 mm x 150 mm x 80 mm
• Power supply 24 VDC 1.5 A
• 4 pairs of safety socket terminals 24 VDC x 4

Stackable test lead set

• Diameter 4 mm
• 5 color coded red, yellow, blue, black and green

Silent oil less air compressor

• Displacement 3 cfm
• Working pressure 7 kg/cm° 7 bar
• 0.5 HP 650 RPM electric motor 240 V 50 Hz single phase

Experimental work table optional

• Heavy duty desktop
• Castor wheel with lock
• 3 layer drawer

Dimensions

• Length 1500 mm
• Width 800 mm
• Height 850 mm

• Modular design allows modifications to suit course or student requirements
• Custom sizes for plug in profile panel board available upon request
• Additional modular components available separately if required
• High quality durable rubber silicone compound on panel ensures components stay in place and easy to remove
• High quality industrial grade components
• Unit comes with various height tilt settings
