Porcelain Furnace

Porcelain Furnace is designed for precise sintering of glass ceramics with a maximum operating temperature of 1300°C. It features a PID intelligent temperature control system with ±1°C accuracy, ensuring consistent and reliable heating. Equipped with a large touchscreen, programmable operation, oil-free vacuum pump, and eco-insulation materials, it delivers efficient, clean, and user-friendly performance for dental and laboratory applications. Manufactured by Atico Export India.

Used for sintering glass ceramics, porcelain restorations, dental prosthetics, ceramic processing, and precision heat treatment in dental laboratories, research laboratories, and material testing facilities.

Maximum Temperature :

• 1300°C

Temperature Accuracy :

• ±1°C

Maximum Vacuum :

• -98 kPa

Heating Rate :

• ≤140°C/min

Programs :

• 100 Programs (Extendable to 500)

Power Consumption :

• 1600 W

Power Supply :

• 220 V, 50/60 Hz

Chamber Dimension :

• Ø100 mm × 70 mm

Dimensions (L × W × H) :

• 380 × 320 × 610 mm

Net Weight :

• 21 kg

Gross Weight :

• 45 kg

• Multi-stage heating
• PID intelligent temperature control
• Large touchscreen with parameterized interface
• Pollution-free operation
• Durable heating wire
• Selectable powder programs
• Oil-free vacuum pump
• Quiet operation
• Eco-insulation material
• Vacuum filtration design
