Portable Density Meter ALB215

Portable Density Meter is designed for accurate measurement of liquid and slurry density using the vibrating fork principle. It offers a wide measuring range with dual display for simultaneous density and medium temperature readings. Featuring frequency tracking, temperature compensation, high-pressure resistance, and IP65 protection, the unit ensures reliable performance in demanding industrial environments. Manufactured by Atico Export India.

Used for accurate measurement of liquid and slurry density in pipelines, open tanks, and closed tank containers across chemical processing, petrochemical, pharmaceutical, food processing, water treatment, and other industrial applications.

Measuring Range :

• 0 to 3 g/cm³

Accuracy :

• 0.001 g/cm³

Resolution :

• 0.0001 g/cm³

Temperature Range :

• -30°C to 120°C

Maximum Working Pressure :

• 20 MPa

Ingress Protection :

• IP65

Power Supply :

• 24 V; 4 to 20 mA

Product Dimension :

• 125 × 125 × 200 mm

Packaging Dimension :

• 450 × 320 × 320 mm

Net Weight :

• 7 kg

Gross Weight :

• 9 kg

Standard Accessories :

• Aluminium alloy digital head
• Five-digit display
• Flange connection
• 150 mm fork length

• Vibrating fork measurement principle
• Frequency tracking
• Plug-in design
• Temperature compensation
• Dual piezo crystals
• High pressure-resistant construction
• Wide temperature range
• Explosion-proof design
• Overpressure protection
• Easy maintenance
• Dual display for density and temperature
