Portable Digital Conductivity Meter for Oil Fuel and Petroleum Testing Instruments

The Portable Digital Conductivity Meter measures the electrical conductivity of aviation and distillate fuels, with or without static dissipater additives. It is designed primarily for hydrocarbon fuels, particularly aviation and jet fuels, and is suitable for laboratory and field applications. The instrument measures rest conductivity when the fuel is electrically at rest and uncharged. It consists of an electronic assembly and a stainless steel probe with concentric electrodes. When immersed in the fluid, a small direct current passes between the electrodes, and the resulting signal is amplified and displayed in picosiemens per meter (pS/m). The meter features single-button operation, a five-digit LCD, automatic test-cycle indication, temperature display in Celsius and Fahrenheit, non-volatile data storage, and automatic over-range and low-battery warnings. Its rugged, hermetically sealed design supports portable operation. Manufactured by Atico Export with a focus on precision, durability, and reliable performance for aviation fuel conductivity testing applications.

Conductivity Range:

• Standard range: 0–2000 pS/m
• Other conductivity ranges available

Resolution:

• ±1 pS/m over the 0–2000 pS/m range

Accuracy:

• 2% of reading

Display:

• Five-digit liquid crystal display (LCD)
• Temperature displayed in Celsius and Fahrenheit
• Text-based operational status presentation
• Automatic over-range indication
• Automatic low-battery indication

Controls and Operation:

• Single push button with dual functions
• Automatic test cycle: 3 seconds
• LED illuminates during the automatic test cycle
• Measurement data retained in non-volatile memory until the next test cycle

Probe and Measurement System:

• Stainless steel probe
• Concentric electrode design
• Electronics assembly amplifies the measured signal
• Banana jack connection for grounding

Power Supply:

• Three standard lithium cells

Operating Temperature Range:

• 32°F to 165°F (0°C to 75°C)

Safety Features:

• Hermetically sealed construction
• Listed by UL and LCIE as intrinsically safe
• UL and ULC-approved components

Standard Accessories:

• Electronic assembly
• Carrying case
• Stainless steel probe
• Instruction manual on CD
• Lithium batteries: 3
• Certificate of calibration
• Ground lead
• UL and ULC approval documentation

Carrying Case:

• Hard, solvent-resistant molded plastic
