Portable Skid Resistance and Friction Tester

The Portable Skid Resistance and Friction Tester measures the frictional resistance between a rubber slider mounted on the end of a pendulum arm and the test surface. This provides highway engineers with a routine method of checking the resistance of wet and dry surfaces to slipping and skidding, both in the lab and on site.

Supplied Complete With
Portable skid resistance and friction tester, adjustable in height, sturdy case with dense foam inserts giving excellent protection.
F Scale Built in, for use with small slider set for 76mm slide length. (PSV test), Perspex setting gauge 126 mm, TRRL3.0, Slider 55 Road Surfaces, Brush, for removing unwanted dirt or grit from area to be tested, C Spanner, for attaching and releasing arm to rotating head, 17mm Spanner for fitting rear foot, Water spray bottle, For wetting surface to be tested, Feet pads, For placing under levelling feet when on soft ground, Operating instructions, A guide to road, floor and PSV testing, Tool set, Manufacturer Calibration Certificate.
Metal base plate without fixing device, TRRL 1.250, Slider 55 PSV Test, FOUR S, Slider 96 Internal Floors, Fixing device to base for blocks and nature stones (EN1341,1342), Fixing device to base for laboratory polished test should be ordered separately.

• Road surface testing
• Testing of new road surface materials under development
• Testing of aggregates in the PSV (polished stone value) test
• Testing of floors and pedestrian walkways
• Flooring materials product development
• Accident investigations, both traffic and pedestrian
• Litigation investigations

STANDARDS COMPLIANCE :

• COMPLIED AS PER BS EN 1097-8, 13036-4:2003, AS/NZS 4586, BS 6077 Pt1, 7044, 7188, 8204, 7976, 812 Pt. 144, ASTM E303

Rocker weight :

• 1500°30 g

Distance between rocking centre and center of gravity :

• 410-5 mm

Positive static pressure on pavement :

• 22.2-0.5 kN

Weight of rubber slider :

• 16 g

Package Aluminum alloy :

• Air transport case

Dimensions :

• 760°740°500 mm

Weight :

• 47 kg

Spare Parts & Accessories :

• Portable skid resistance and friction tester, adjustable in height
• Sturdy case with dense foam inserts giving excellent protection
• F Scale Built in, for use with small slider set for 76mm slide length. (PSV test)
• Perspex setting gauge 126 mm
• TRRL3.0, Slider 55 Road surfaces
• Brush, For removing unwanted dirt or grit from area to be tested
• C Spanner, For attaching and releasing arm to rotating head
• 17mm Spanner For fitting rear foot
• Water spray bottle, For wetting surface to be tested
• Feet pads, For placing under levelling feet when on soft ground
• Tool set
• Metal base plate without fixing device
• TRRL 1.250, Slider 55 PSV Test
• FOUR S, Slider 96 Internal Floors
• Fixing device to base for blocks and nature stones (EN1341,1342)
• Fixing device to base for laboratory polished test

• Designed for laboratory and in situ road surface testing
• Dispatch calibrated to ASTM E-303
• Low friction arm, and lightweight pointer
• Comes with integral scale for use with small slider set for 76mm slide length. (PSV test)
• Repeatable and reproducible
• Supplied with robust carrying case
