Position sensor characteristic Physics Lab Experiment Setup

This experiment system is designed for studying position sensor characteristics and the mechanical and thermal properties of materials. It enables the calibration of position sensors, determination of Young’s modulus using both bending beam and tensile methods, and measurement of the linear expansion coefficient of materials. The system provides precise displacement, force, and temperature measurements, making it suitable for advanced physics and engineering laboratory applications.

Manufactured by Atico Export India.

Experimental Principle and Content

• Measurement of Position Sensor Characteristics
• Calibration of Position Sensors
• Determination of Young’s Modulus by the Bending Beam Method
• Determination of the Linear Expansion Coefficient of Materials
• Determination of Young’s Modulus by the Tensile Method

Calibration System :

• Micrometer Calibration Device
• Convenient, Accurate, and Intuitive Reading

Heating System :

• Safe Low-Voltage Heating
• Temperature Range: Room Temperature to 120°C

Temperature Measurement :

• Range: -50°C to 125°C
• 3½-Digit Digital Display
• Accuracy: ±0.1°C

Digital Tensile Measuring Instrument :

• Range: 0–199 kg
• Accuracy: ±0.01 kg
