Power Distribution & Protection Trainer

• Identify the challenges and solutions to power distribution protection problems.
• Regulation of two transmission lines carrying AC or DC current.
• Analyze the variations of distribution feeder systems (Radial and Ring System).
• Study how reactive power affects and regulates the voltage throughout the system.
• Analyze distribution losses and efficiency.

Fault in a distribution system.

• Voltage control in the distribution transformer tap changer.
• Circuit analysis of 3 Phase System in balanced and unbalanced condition.

• Analyze the effect of improved power factor on line current.
• Analyze the effect of an open-circuited neutral conductor on voltage that appears in a phase load.
