Power Electronics Trainer 6 APPL Inverters

This trainer is designed for practical study of electronic switching, control, and power electronic circuits. It provides a suitable platform for understanding the operation of MOSFET, UJT, TRIAC, DIAC, LDR, SCR, pulse transformer, timer ICs, and related electronic components through hands-on experiments. The trainer supports both DC motor and AC bulb loads for practical demonstrations. The unit is housed in a metal cabinet and features a clearly printed insulated circuit board. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Power Supply:

• Mains supply: 0–220 V AC.
• Mains operated: 230 V, 50 Hz ±10%.

Components Mounted on Panel:

• MOSFET.
• UJT.
• TRIAC.
• DIAC.
• LDR.
• SCR.
• Pulse transformer: 1:1.
• Timer IC.
• Operational amplifier IC.
• IGBT.
• Diodes, resistors, variable resistors, and capacitors.

Loads:

• DC motor as load.
• AC bulb: 230 V.

• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• Protective cover.
• 4 mm patch cords.
• Supplied through a 3-pin computer socket with appropriate fuse.
• Housed in a metal cabinet.
• Trainer size: 15 × 11 inches.
