Power Electronics Trainer PET V2

The Power Electronics Trainer is designed for comprehensive practical study of power semiconductor devices, their characteristics, triggering techniques, rectifier circuits, switching, and AC phase-control applications. It provides experiments covering SCR, TRIAC, UJT, MOSFET, IGBT, DIAC, PUT, power transistor, and power diode characteristics. The trainer also supports digital firing, UJT triggering, resistor-capacitor triggering, rectification, TRIAC switching, and AC phase-control experiments. It includes multiple power supplies, digital meters, semiconductor devices, capacitors, inductors, potentiometers, a pulse transformer, breadboards, and selectable loads for practical circuit development. The trainer is housed in a wooden cabinet and is suitable for hands-on physics and electronics laboratory training. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Scope of Learning

• Study the V-I characteristics of SCR.
• Study SCR gate control characteristics and triggering.
• Study the characteristics of UJT.
• Study the characteristics of MOSFET.
• Study the characteristics of IGBT.
• Study the V-I characteristics of DIAC.
• Study the V-I characteristics of TRIAC.
• Study the characteristics of PUT.
• Study resistor triggering circuits.
• Study half-wave resistor-capacitor triggering circuits.
• Study full-wave resistor-capacitor triggering circuits.
• Study SCR triggering using UJT.
• Study digital firing circuits.
• Study SCR triggering using digital techniques.
• Study TRIAC triggering techniques.
• Study UJT triggering techniques.
• Study MOSFET triggering techniques.
• Study IGBT triggering techniques.
• Study power transistor characteristics.
• Study SCR half-controlled rectifier circuits.
• Study SCR full-controlled rectifier circuits.
• Study UJT relaxation oscillator.
• Study TRIAC switching circuits.
• Study TRIAC AC phase-control circuits.

Power Supplies:

• +5 V at 250 mA.
• +15 V at 250 mA.
• 0–15 V at 250 mA.
• 0–30 V at 250 mA.
• 18–0–18 V at 150 mA.
• 15–0–15 V at 250 mA.
• Mains operated: 230 V, 50 Hz ±10%.

Digital Meters:

• Dual-range voltmeter/ammeter: 20 V / 20 mA.
• Dual-range ammeter: 20 mA / 200 mA.
• Dual-range voltmeter: 20 V / 200 V.

Device Assemblies:

• SCR assembly: 4 SCRs, rated up to 600 V, 2 A.
• MOSFET assembly: 4 MOSFETs.

Power Devices:

• IGBT.
• MOSFET.
• UJT.
• DIAC.
• TRIAC.
• SCR.
• Power transistor.
• PUT.
• Power diode.

Capacitors on Board:

• 103K capacitor.
• 473K capacitor.
• 1 µF capacitor.
• 334K capacitor.
• 10 µF capacitor.

Inductors:

• 10 mH.
• 50 µH.
• 220 µH.
• 5 µH.

Load Resistance Using Rotary Switch:

• 120 Ω, 220 Ω, 500 Ω, 1 KΩ, 2 KΩ, and 10 KΩ.
• Each rated at 5 W.

Resistors on Board:

• 10 Ω / 5 W.
• 47 Ω / 5 W.
• 47 KΩ / 1 W.
• 100 KΩ / 1 W.
• 10 KΩ / ¼ W.
• 10 KΩ / 10 W.
• 1 KΩ / 10 W.
• 4.7 KΩ / ¼ W.
• 2 KΩ / 1 W.

Potentiometers:

• 470 KΩ: 1 unit.
• 10 KΩ: 1 unit.

Pulse Transformer:

• 1:1:1 pulse transformer.

Breadboard:

• 850-point breadboard: 2 units.

Loads:

• Lamp.
• 12 V DC motor.

Firing Circuits on Board:

• Line synchronization firing control circuit.
• PWM firing control circuit for frequency control.
• TRIAC firing control circuit.

• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• 2 mm patch cords.
• High-voltage test points with 2 mm safety sockets.
• Attractive wooden cabinet.
• Trainer size: 15 × 11 inches.
