Power Electronics Trainer PET V2 Modular

The Power Electronics Trainer is a modular training system designed for comprehensive practical study of power semiconductor devices, their characteristics, triggering techniques, rectifier circuits, switching, and AC phase-control applications. It supports experiments on SCR, TRIAC, UJT, MOSFET, IGBT, DIAC, PUT, power transistor, and power diode characteristics. The trainer also covers digital firing, UJT triggering, resistor-capacitor triggering, rectification, TRIAC switching, and AC phase-control experiments. Its modular design allows practical study using dedicated experimental circuits and interchangeable modules. Designed and manufactured by Atico Export to meet the practical demands of modern laboratories.

Scope of Learning

• Study the V-I characteristics of SCR.
• Study SCR gate control characteristics and triggering.
• Study the characteristics of UJT.
• Study the characteristics of MOSFET.
• Study the characteristics of IGBT.
• Study the V-I characteristics of DIAC.
• Study the V-I characteristics of TRIAC.
• Study the characteristics of PUT.
• Study resistor triggering circuits.
• Study half-wave resistor-capacitor triggering circuits.
• Study full-wave resistor-capacitor triggering circuits.
• Study SCR triggering using UJT.
• Study digital firing circuits.
• Study SCR triggering using digital techniques.
• Study TRIAC triggering techniques.
• Study UJT triggering techniques.
• Study MOSFET triggering techniques.
• Study IGBT triggering techniques.
• Study power transistor characteristics.
• Study SCR half-controlled rectifier circuits.
• Study SCR full-controlled rectifier circuits.
• Study UJT relaxation oscillator.
• Study TRIAC switching circuits.
• Study TRIAC AC phase-control circuits.

Power Supplies:

• +5 V at 250 mA.
• ±15 V at 250 mA.
• 0–15 V at 250 mA.
• 0–30 V at 250 mA.
• 18–0–18 V at 150 mA.
• 15–0–15 V at 250 mA.
• Mains operated: 230 V, 50 Hz ±10%.

Digital Meters:

• Dual-range voltmeter/ammeter: 20 V / 20 mA.
• Dual-range ammeter: 20 mA / 200 mA.
• Dual-range voltmeter: 20 V / 200 V.

Device Assemblies:

• SCR assembly: 4 SCRs, rated up to 600 V, 2 A.
• MOSFET assembly: 4 MOSFETs.

Power Devices:

• IGBT.
• MOSFET.
• UJT.
• DIAC.
• TRIAC.
• SCR.
• Power transistor.
• PUT.
• Power diode.

Capacitors on Board:

• 103K capacitor.
• 473K capacitor.
• 1 µF capacitor.
• 334K capacitor.
• 10 µF capacitor.

Inductors:

• 10 mH.
• 50 µH.
• 220 µH.
• 5 µH.

Load Resistance Using Rotary Switch:

• 120 Ω, 220 Ω, 500 Ω, 1 KΩ, 2 KΩ, and 10 KΩ.
• Each rated at 5 W.

Pulse Transformer:

• 1:1:1 pulse transformer.

Breadboard:

• 850-point breadboard: 2 units.

Loads:

• Lamp.
• 12 V DC motor.

Firing Circuits on Board:

• Line synchronization firing control circuit.
• PWM firing control circuit for frequency control.
• TRIAC firing control circuit.

• Modular design for practical experimentation.
• Front panel with high-class insulated printed circuit board featuring clearly printed circuits and symbols.
• Instruction manual.
• 2 mm patch cords.
• High-voltage test points with 2 mm safety sockets.
• Housed in an attractive wooden cabinet.
• Trainer size: 15 × 11 inches.
