Power Electronics Training System

The system combines power electronics and control, with wide applications of solid-state electronics for the control and conversion of electric power. Common power electronics circuits include:

• 1. Rectifiers
• 2. Choppers
• 3. Inverters

The experimental modules include:

• 1. Converter modules
• 2. Power supply modules
• 3. Load modules
• 4. Control modules
• 5. Testing modules

These modules and instruments are introduced and demonstrated through subsequent experiments.
