Power Project Board

AC adaptor jack :

• I/P DC + 8V, 1.5A

Pulse switch :

• Two bounce-free push-buttons

Logic switch :

• Eight logic level switches in DIP type

DC O/P :

• DC + 5V, 750mA for user

breadboard :*

• Solderless breadboard with 1580 interconnected tie points

Clip terminal :

• Logic probe clip terminal

LED display :

• Eight LED buffered logic level indicators
• BNC jacks
• Banana jacks

Clock adjustment :

• Fine adjustment of clock frequency

Select switch :

• Clock range selection
• L: 10–40Hz, H: 1K–20KHz
